LED Module System IP66 130Lm/w 50W to 600W LED High Bay Light LED Industrial Light

Product Description

LED Module System IP66 130Lm/w 50W to 600W LED High Bay Light LED Industrial Light

Product Show



A high bay light is a high-performance luminarie for warehouses, factories, gyms and other high ceiling environments.Being used in the most demanding conditions,our high bay lights are designed for the maximum efficiency and IP65 protection industrial areas.The fin-shaped design heat sink increases the conductivity and air circulation, the body of metal alloy highly reduces the weight of the lamp.













































Technical Data



Model	Watts	Input Voltage	Lumens	Ra	PFD	IP
LS-YTM-50W	50W	AC85-277V 50/60Hz or Other	7000Lm	80	0.95	66
LS-YTM-100W	100W	AC85-277V 50/60Hz or Other	14000Lm	80	0.95	66
LS-YTM-150W	150W	AC85-277V 50/60Hz or Other	21000Lm	80	0.95	66
LS-YTM-200W	200W	AC85-277V 50/60Hz or Other	28000Lm	80	0.95	66
LS-YTM-250W	250W	AC85-277V 50/60Hz or Other	35000Lm	80	0.95	66
LS-YTM-300W	300W	AC85-277V 50/60Hz or Other	42000Lm	80	0.95	66
LS-YTM-400W	400W	AC85-277V 50/60Hz or Other	56000Lm	80	0.95	66
LS-YTM-500W	500W	AC85-277V 50/60Hz or Other	70000Lm	80	0.95	66
LS-YTM-600W	600W	AC85-277V 50/60Hz or Other	84000Lm	80	0.95	66





























Product Features

• Brand 3030 LED Chip ensures the light gentle, well-distributed and of high brightness;
• AC95-305V MEANWELL driver input voltage allows the light works well in all condition;
• Heatsink of cold forging processing ensures good dissipation performance;
• Lamp body made of anodized aluminum 1070 means the good anti-corrosion,intensity and suitable for even a bad climate;
• Optical PC Lens transmittance of 94% and light efficacy 140Lm/w;
• Multiple Light Distribution Designs: 10°/25°/45°/60°/90°with longer bracket, suitable for many applications;
• Stable Electro Magnetic Compatibility;
• Quick start with no flicker or noise.
